12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator Q4 Model

I'm Online Chat Now

12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator Q4 Model

12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator  Q4 Model
12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator  Q4 Model 12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator  Q4 Model 12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator  Q4 Model 12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator  Q4 Model

Large Image :  12V/24V 300W/400W/500W Small Vertical Wind Turbine Generator Q4 Model

Product Details:

Place of Origin: China
Brand Name: AP
Certification: CE
Model Number: Model AP-300Q4 AP-400Q4 AP-500Q4

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Packaging Details: Standard Export Package
Delivery Time: 20 Days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000PCS
Detailed Product Description
Blades Material: Aluminum Alloy

Model AP-300Q4 AP-400Q4 AP-500Q4
Rated power 300W 400W 500W
Maximum power 310W 410W 510W
Rated voltage 12V/24V 12V/24V 24V
Start up wind speed 1.5m/s 1.5m/s 1.5m/s
Rated wind speed 11m/s 11m/s 12m/s
Survival wind speed 45m/s 45m/s 45m/s
Top net weight 25kg 26kg 27kg
Wheel diameter 1.4m 1.4m 1.4m
Blades number 4
Blades material Aluminum alloy
Generator Three phase permanent magnet ac generator/ maglev generator
Control system Electromagnet
Speed regulation Automatically windward
Working temperature -40℃~80℃
