Product Details:
Payment & Shipping Terms:
|
Features :
1.High-end chip,high-performance CPU,improve the working reliability.
2.Overvoltage,low voltage,over temperature,overload,short circuit,reverse connection protection.
3.Sound and light alarm,under-voltage alarm,with frequency-conversion cooling fan.
4.Soft-start function,increase loading capacity.
5.Aluminum alloy shell,Heat eliminable.
6.With battery clip and manual..
| Power Rating | 350W | 500W | 1000W | ||||||||||
| Continue Output Rating | 350W | 500W | 1000W | ||||||||||
| Peak Power Rating Output | 700W | 1000W | 2000W | ||||||||||
| Input Section | DC Input Voltage | 12V | 24V | 48V | 60V | 12V | 24V | 48V | 60V | 12V | 24V | 48V | 60V |
| DC Operating Voltage | 11-15V | 21-29V | 40-50V | 60.5-72V | 11-15V | 21-29V | 40-60V | 60.5-72V | 11-15V | 21-29V | 40-60V | 40-60V | |
| DC Low-voltage Protection | 9-10.5V | 18.5-20.5V | 39V | 58.5-60.5V | 9-10.5V | 18.5-20.5V | 39-40V | 58.5-60.5V | 9-10.5V | 18.5-20.5V | 39-40V | 39-40V | |
| DC Low-voltage Alarm | 9.5-11V | 19.5-21V | 40V±1 | 59-61V | 9.5-11V | 19.5-21V | 39-41V | 59-61V | 9.5-11V | 19.5-21V | 39-41V | 39-41V | |
| DC Over-voltage Protection | ≥15V | ≥29V | ≥29V | ≥72V | ≥15V | ≥29V | ≥60V | ≥72V | ≥15V | ≥29V | ≥60V | ≥60V | |
| Fuse | 40A*1 | 20A*2 | 20A*2 | 20A*2 | 40A*2 | 20A*2 | 10A*3 | 10A*2 | 40A*3 | 20A*3 | 15A*4 | 15A*4 | |
| Quiescent Current | ≤0.5A | ≤0.5A | ≤0.5A | ≤0.5A | ≤0.6A | ≤0.6A | ≤0.5A | ≤0.5A | ≤1A | ≤1A | ≤1A | ≤1A | |
| Output Section | Output Waveform | Pure Sine Wave | |||||||||||
| Output Voltage | 220V±10% | ||||||||||||
| Output Frequency | 50Hz±1% | ||||||||||||
| Transfer Efficiency | ≥93% | ||||||||||||
| Overload Protection | 350W--420W | 500W--600W | 1000W--1200W | ||||||||||
| Short-circuit Protection | Yes | ||||||||||||
| Operating Temperature | -10℃--+50℃ | ||||||||||||
| Temperature Protection | +60℃--+70℃ | ||||||||||||
| Green LED Indicator | Green Light(Working),Flash(Overload Protection) | ||||||||||||
| Red LED Indicator | Red Light(Error Protection) | ||||||||||||
