24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator M4 Model

I'm Online Chat Now

24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator M4 Model

24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator  M4 Model
24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator  M4 Model 24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator  M4 Model 24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator  M4 Model 24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator  M4 Model

Large Image :  24V/48V 600w/700w High Efficient fan Type Wind Turbine Generator M4 Model

Product Details:

Place of Origin: China
Brand Name: AP
Certification: CE
Model Number: AP-600M4 AP-700M4

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Packaging Details: Standard Export Package
Delivery Time: 20 Days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000PCS
Detailed Product Description
Blades Material: Nylon Fiber

Model AP-600M4 AP-700M4
Rated power 600W 700W
Maximum power 630W 720W
Rated voltage 24V/48V 24V/48V
Start up wind speed 2.5m/s 2.5m/s
Rated wind speed 11m/s 11m/s
Survival wind speed 45m/s 45m/s
Top net weight 20kg 21kg
Wheel diameter 1.85m 1.85m
Blades number 3
Blades material Nylon fiber
Generator Three phase permanent magnet ac generator
Magnetic steel NdFeB
Generator case Die-casting aluminum
Control system Electromagnet
Speed regulation Automatically adjust windward
Working temperature -40℃~80℃
