Features :
1.High-end chip,high-performance CPU,improve the working reliability.
2.Overvoltage,low voltage,over temperature,overload,short circuit,reverse connection protection.
3.Sound and light alarm,under-voltage alarm,with frequency-conversion cooling fan.
4.Soft-start function,increase loading capacity.
5.Aluminum alloy shell,Heat eliminable.
6.With battery clip,AC input wire and Manual.
| Model No. | AP-2000W/12V/F/A | AP-2000W/24V/F/A | |
| Size | 275 x 165 x 125mm | ||
| Weight | 4.5Kg | 4.5Kg | |
| Certificate | CE and ROHS | ||
| DC Input | DC Input Voltage | 12V | 24V |
| section | DC Operating Voltage | 11-15V | 21-29V |
| DC Low-voltage Protection | 9-10.5V | 18.5-20.5V | |
| DC Low-voltage Alarm | 9.5-11V | 19.5-21V | |
| DC Over-voltage Protection | ≥15V | ≥29V | |
| Fuse | 35A*3 | 35A*3 | |
| Quiescent Current | ≤1.6A | ≤1.6A | |
| AC input | AC input voltage | 220v | |
| Section | AC inout frequency | 50Hz | |
| AC operating voltage | 170-250v | ||
| AC Low-voltage Protection | ≤150v | ||
| AC over-voltage Protection | ≥250v | ||
| Ac input Frequency | 50Hz | ||
| Working and Protection | Transfer Efficiency | ≥90% | |
| Overload Protection | 2000W--2400W | ||
| Short-circuit Protection | Yes | ||
| Start | soft-start function | ||
| Operating Temperature | -10°C--+50°C | ||
| Temperature Protection | +60°C--+70°C | ||
| Green LED Indicator | Green Light(Working),Flash(Overload Protection) | ||
| Red LED Indicator | Red Light(Error Protection) | ||
| Other | Warranty | 2 years | |
| Packing | Color box packing or skin packing | ||
| Model No. | AP-3000W/12V/F/A | AP-3000W/24V/F/A | |
| Input Section | DC Input Voltage | 12V | 24V |
| DC Operating Voltage | 11-15V | 21-29V | |
| DC Low-voltage Protection | 9-10.5V | 18.5-20.5V | |
| DC Low-voltage Alarm | 9.5-11V | 19.5-21V | |
| DC Over-voltage Protection | ≥15V | ≥15V | |
| Fuse | 40A*3 | ||
| Quiescent Current | ≤1A | ||
| Output Section | Output Waveform | Modified Sine Wave | |
| Output Voltage | 220V±10% | ||
| Output Frequency | 50Hz±1% | ||
| Power Rating | 3000W | ||
| Continue Output Rating | 3000W | ||
| Peak Power Rating Output | 6000W | ||
| Transfer Efficiency | ≥90 % | ||
| Overload Protection | 3000W--3600W | ||
| Short-circuit Protection | Yes | ||
| Operating Temperature | -10°C--+50°C | ||
| Temperature Protection | +60°C--+70°C | ||
| Green LED Indicator | Green Light(Working),Flash(Overload Protection) | ||
| Red LED Indicator | Red Light(Error Protection) | ||
| Size | Size: 305 x 165 x 125mm | ||
| Weight | 4.8kg | ||
| Packing | Color box packing or skin packing | ||
